Single-sided Window Tent Stove

Overview of the Single-sided Window Tent Stove

The Single-sided Window Tent Stove is a folding wood-burning tent stove manufactured by Yongkang Luling Industry and Trade Co., Ltd. It is built for heating, cooking, and boiling water in tents and shelters. The stove folds flat but is not detachable: the body is not separated into panels. The sectional smoke pipes store inside the firebox, and the folded unit can be carried in a storage bag, which is sold separately. Two versions are offered: black carbon steel (Z360H) and silver stainless steel (Z360B).

Key Features of the Single-sided Window Tent Stove

Folding body with internal pipe storage

The body folds as a single unit to 390 × 210 × 250 mm. The smoke pipe sections are stored inside the firebox through the front door, so the complete kit occupies one carton with fewer loose parts at the campsite.

Glass windows for radiant heating

A square glass window is fitted in the front loading door, and one long rectangular glass window runs along a single side. The windows allow the fire to be checked and provide radiant heat transfer into the tent.

Folding side racks

Wire racks on both sides fold outward for drying gloves, holding cups, or supporting skewers, and can be raised over the top plate as a warming frame.

Cooking surface and four independent legs

The flat top plate holds kettles and pans, and the round cap opens for direct-flame cooking. Four independent folding legs with non-slip feet support the stove, and a pull-out ash drawer below the firebox collects ash.

Accessories and Packaging for the Single-sided Window Tent Stove

The standard kit includes smoke pipes, a hook, a pair of gloves, and a screwdriver. The smoke pipe specification is 320mm × 60mm × 5 sections (12.6in × 2.36in × 5). The 360 storage bag is not included in the standard kit and is sold separately. Each unit is wound with plastic film, clamped between EPS foam boxes, and packed in a five-layer A&B-grade corrugated cardboard carton.

Recommended Applications of the Single-sided Window Tent Stove

The stove is suitable for bell tents, wall tents, winter camping, and glamping rental operators. Commercial users can contact the manufacturer for the current unit price, freight quotation based on the 450 × 320 × 280 mm packed size, material and glass options, and the separately supplied storage bag.

MATERIAL	SIZE			WEIGHT / kg		ACCESSORIES	SMOKE PIPE SIZE	REMARKS
	UNFOLD	FOLD	PACK	N.W	G.W
carbon steel	400*530*350mm	390*210*250mm	450*320*280mm	8.2	8.8	Some smoke pipes,a hook,a pair of gloves,A screwdriver	320mm*60mm*5 12.6in*2.36in*5	glasses size： ①100*50*5mm/110*110*5mm 3.94*1.97*0.2in/4.33*4.33*0.2in （optional） ②270*100*4mm 10.63*3.94*0.16in

FAQ About the Single-sided Window Tent Stove

Is the Single-sided Window Tent Stove detachable or foldable?

It is foldable only. The body folds flat as a single unit and the smoke pipes store inside the firebox; the panels do not separate. A storage bag for the folded kit is sold separately.

What smoke pipe size is supplied with the Single-sided Window Tent Stove?

The smoke pipe specification is 320mm × 60mm × 5 sections, equal to 12.6in × 2.36in × 5. The sections are carried inside the firebox.

What are the glass window sizes on the Single-sided Window Tent Stove?

The front door glass is supplied as either 100 × 50 × 5 mm or 110 × 110 × 5 mm (3.94 × 1.97 × 0.2 in or 4.33 × 4.33 × 0.2 in, optional), and the long side window is 270 × 100 × 4 mm (10.63 × 3.94 × 0.16 in).

What are the dimensions and weight of the Single-sided Window Tent Stove?

The carbon steel version unfolds to 400 × 530 × 350 mm, folds to 390 × 210 × 250 mm, and packs to 450 × 320 × 280 mm. Net weight is 8.2 kg for carbon steel and 8 kg for stainless steel; gross weight is 8.8 kg and 8.6 kg.

Is a storage bag included with the Single-sided Window Tent Stove?

No. The 360 storage bag is not included in the standard kit and is sold separately.

Does the Single-sided Window Tent Stove have electronic controls?

No. Airflow is adjusted manually with the push-pull vent knob and the top damper disc. There are no electronic switches, regulators, or powered ignition parts.
